106kWh LFP BATTERY
LFP battery system provides 106kWh capacity at 461V and supports an urban combined driving range of 300km.
DESIGN
SANY Electric Light Truck "Left-Hand Drive" Version
POWER Electric Reliable Performance
ELECTRIC MOTOR
PMSM electric motor provides 60kW rated power, 115kW peak power and up to 350N·m peak torque.
FAST CHARGING
Supports DC fast charging plus 6.6kW single-phase AC220V trickle charging, with 20%-80% charging in 40 minutes or less.
ENERGY REGENERATION
The braking system integrates energy regeneration together with EHB, ABS and ESC functions.
SAFETY & RELIABILITY
HIGH-STRENGTH CHASSIS
Large-section high-strength steel straight-through beam chassis supports demanding light commercial transport applications.
6000kg GVWADVANCED BRAKING
EHB, ABS and ESC are combined with braking energy regeneration for controlled and efficient operation.
EHB+ABS+ESCPAYLOAD CAPABILITY
Box-type cargo configuration supports a stated payload of 2940kg.
2940kgGRADEABILITY
Electric drivetrain provides maximum gradeability of at least 20%.
≥20%COMPACT TURNING
Minimum turning radius is less than 7 metres for improved urban manoeuvrability.
<7mURBAN RANGE
Combined urban driving range is stated at 300km.
300km
LOW ENERGY CONSUMPTION
DRIVING THE FUTURE OF GREEN TRANSPORT
Systematic energy-saving technology delivers approximately 10% lower power consumption than industry mainstream competitors, while regenerative braking helps recover energy during operation.
A PROFITABLE INVESTMENT
Power Consumption Reduction
10 %Estimated Operating Savings
500 $Brochure states approximately 10% lower power consumption than industry mainstream competitors. Actual operating savings depend on distance, payload, electricity tariff and operating conditions.
SPECIFICATION
| Model | 6 Ton 106kWh | 6 Ton 106kWh |
|---|---|---|
| Configuration | Class II Chassis | Box-type Cargo Container |
| Drive Position | Left-Hand Drive | Left-Hand Drive |
| External Dimensions (mm) | 5975×2170×2285 | 5995×2185×3120 |
| Cargo Body Type | — | Aluminum Alloy Cargo Box |
| Cab Width / Seats | 2040mm / 3 | 2040mm / 3 |
| Wheelbase (mm) | 3360 | 3360 |
| Container Inner Dimensions (mm) | — | 4180×2100×2100 |
| Curb Weight (kg) | 2550 | 3060 |
| Payload (kg) | 2940 | 2940 |
| GVW (kg) | 6000 | 6000 |
| EEC (kg) | 6000 | 6000 |
| Maximum Speed | 90 km/h | 90 km/h |
| Maximum Gradeability | ≥20% | ≥20% |
| Minimum Turning Radius | <7m | <7m |
| Urban Combined Driving Range | 300km | 300km |
| Battery Type | LFP | LFP |
| Battery Capacity | 106kWh | 106kWh |
| Battery Voltage | 461V | 461V |
| Energy Supply | DC Fast Charging + AC Trickle Charging | DC Fast Charging + AC Trickle Charging |
| AC Trickle Charging | 6.6kW Single-phase AC220V | 6.6kW Single-phase AC220V |
| Charging Standard | European Standard / Chinese Standard GB/T | European Standard / Chinese Standard GB/T |
| Charging Time | 20%-80% ≤40min | 20%-80% ≤40min |
| Motor Category | PMSM | PMSM |
| Rated Motor Power | 60kW | 60kW |
| Peak Motor Power | 115kW | 115kW |
| Rated Motor Torque | 135N·m | 135N·m |
| Peak Motor Torque | 350N·m | 350N·m |
| Leaf Springs | Front 3 / Rear 3+3 | Front 3 / Rear 3+3 |
| Brake System | EHB + ABS + ESC + Braking Energy Regeneration | EHB + ABS + ESC + Braking Energy Regeneration |
| Parking Brake | EPB | EPB |
| Tyres | 7.00R16LT (ECE) / 215/75R17.5 | 7.00R16LT (ECE) / 215/75R17.5 |
| Tyre Rim | All Aluminum / All Steel | All Aluminum / All Steel |
| AEBS + LDW + FCW | Brochure marked ○ | Brochure marked ○ |
| 360 Camera / Fatigue Monitoring System | — | — |
| TPMS | — | — |
| Headlamp | LED / LED + Auto Headlights | LED / LED + Auto Headlights |
| Windscreen Wiper | Hand Wiper / Auto Wiper | Hand Wiper / Auto Wiper |
| Rear Mirror | Electric Heating + Manual Adjustment | Electric Heating + Manual Adjustment |
| Air Conditioning | Cooling + Heating | Cooling + Heating |
| Standard Cab Equipment | Column Shifter, 7-inch LCD Instrument Panel, 12-inch Central Control Screen, Back-up Camera and Radar, Multi-function Steering Wheel, Central Locking, Power Windows, LED Daytime Running Lights | Column Shifter, 7-inch LCD Instrument Panel, 12-inch Central Control Screen, Back-up Camera and Radar, Multi-function Steering Wheel, Central Locking, Power Windows, LED Daytime Running Lights |
| Price | Contact Sales | Contact Sales |
